- Available in 6
- 8
- 10
- 12 ton single module which can be combined up to 36-tons capacity
- Ability to connect up to 64 multiple style indoor units with a triple module outdoor unit
- Piping flexibility up to 3280 ft
- High performance outdoor units with all inverter-driven scroll compressor
- DC inverter condenser fan motor
- 208/230-3-60Hz or 460-3-60Hz voltage
- Cooling ambient operating temperature is 14⁰ F to 122⁰ F and heating ambient operating temperature is -4⁰ F to 60⁰ F
- Connected capacity is up to 135%
- RELIABILITY FEATURES
- All equipment wiring complies with NEC requirements
- Unit constructed in accordance with ETL requirements
- Unit performance is in accordance with AHRI 1230 standards
- Compressor and condenser fan motor are inverter driven
- Finned tube heat exchanger
- Suitable for R-410a refrigerant
- INSTALLATION FEATURES
- System utilizes 2-pipes to connect to up to 64 indoor units
- Integrated controls design allows for complete system control
- System can be auto addressed
- System utilize quick connect controls system
